The GPD WIN Mini 2024 sets a new standard with its AMD Ryzen 7 8840U with 8 cores and 16 threads up to 5.1Ghz, pushing the limits of what’s possible in a handheld device. With powerful AMD Radeon 780M GPU, delivering desktop-level performance in a compact form. This ensures smooth, high-fidelity gaming experiences, efficient multitasking, and seamless application use.
A 7-inch 120Hz high refresh rate gaming screen specially designed for WIN Mini. It features native landscape, 6th generation Corning Gorilla Glass, LTPS technology, supports VRR (Variable Refresh Rate) and AMD FreeSync Premium. No more worrying about game screen tearing!
Equipped with 32GB LPDDR5 RAM and options for 1TB NVMe SSD storage, the GPD WIN Mini 2024 offers lightning-fast load times and ample space for games, applications, and data. This combination guarantees a responsive and fluid experience, whether you’re gaming, working, or browsing.
2024 version WIN Mini adds a new USB4 interface, with a bandwidth of 40Gbps and native support for Thunderbolt 3 protocol, allowing connection to GPD G1 or third-party graphics card docks to play AAA titles. It supports an external 8K@60Hz display and PD fast charging protocol.
GPD WIN Mini 2024 delivers a rich user experience, running Windows 11 and supporting a vast ecosystem of games, apps and emulators. The 7-inch 120Hz 1080P touchscreen delivers crystal-clear visuals, while multi-function I/O (including USB4 and microSD slots) keeps all your devices connected. A precision touchpad, Hall-effect joystick and programmable macro buttons provide precise control, enhancing gameplay and productivity. With WiFi 6 and Bluetooth 5.2, it can stay connected in any setting, making it ideal for modern gaming and retro enthusiasts alike.
| General |
Brand: GPD |
| Display | Characteristic: 120Hz Gaming Screen, Native Landscape, Supports VRR, AMD FreeSync™ Premium, Flip Design, Infinite Hinge, Maximum Opening Angle Of 168 Degrees Touch Panel: Support, 10-point Touch Control Screen Type: The Sixth Generation Of Corning Gorilla Glass, LTPS Technology, AF+AR Coating, 500nit Screen Size: 7 Inches Refresh Rate: 60Hz / 120Hz Aspect Ratio: 16:9 Screen Resolution: 1920×1080 Pixels Per Inch: 314 PPI |
| CPU | Model: AMD Ryzen 7 8840U Cores/Threads: 8C/16T Base Clock: 3.3 GHz Max. Boost Clock: 5.1 GHz AI Performance: 16 TOPS Total Processor Performance: 38 TOPS Total Cache: 24.5 MB Architecture: Zen 4 (Hawk Point) Process Size: 4nm TDP: 15W-30W |
| GPU | Processor Graphics: AMD Radeon 780M Graphics Frequency: 2700 MHz Compute Units: 12CU Shading Units: 768 Floating-point Performance: 17.82 TFlops (FP16), 8.92 TFlops (FP32), 556.8 GFlops (FP64) Pixel Rate: 92.80 GPixel/s Texture Rate: 139.2 GTexel/s Video Memory: Shared Memory HDMI: 7680 x 4320 @60Hz DP: 7680 x 4320 @60Hz DirectX: DX12 Ultimate OpenGL: 4.6 |
| Storage | Memory: 32GB Memory Types: LPDDR5 6400 MT/s Memory Dual Channel: Quad 32-bit Channels Hard Disk Type: M.2 SSD Hard Disk Interface: M.2 (Socket 3) x 1 Supported Specifications: M.2 NVMe 2230 x 1 Storage: 1TB Bus Specification: PCIe 4.0 x 4 Transfer Protocol: NVMe 1.3/1.4 |
| Multimedia Support | Audio System: Built-In Audio Chipset Loudspeakers: Equipped With 2 Built-In Hyper-Linear Speakers, Both Headphones And Speakers Support DTS: X Sound Effects, Which Can Simulate The Sound Effects Of A Physical 7.1 Channel Microphone: Built-In Microphone |
| Network | Wi-Fi 6: IEEE 802.11 a/b/g/n/ac/ax, Support 2.4G/5G Dual Frequency Band, Dual Channel Maximum Transmission Rate 2402Mbps MU-MIMO: Supports Bluetooth: 5.2 |
| I/O Interface | Video/Data/Charging: 1 x USB4 (40Gbps), 1 x USB 3.2 Gen 2 Type-C (10Gbps), 1 x USB 3.2 Gen 2 Type-A (10Gbps) microSD Slot: SD 3.0 Protocol, Bus interface: UHS-I, Video Speed Class: V30, I/O Performance: A2, Theoretical Speed: Read 160MB/s, Write 120MB/s, Compatible: microSDHC / microSDXC / microSDUC Audio Port: 1 x 3.5mm Headphone/Microphone Combo Jack, Compatible with Apple Headphones (US version) BIOS Reset Port: Supports |
| I/O Device | Power Switch: Power Button Keyboard: QWERTY Full Keyboard, Scissor-Switch Keys, Backlit Design Indicator Lamp: Charging Indicator Light TouchPad: Precision Touchpad (PTP Mode), Supports Up To 4-Finger Gestures Mouse: Joystick For Simulating Mouse, Requires Switching Between "Gamepad/Mouse" Modes Joystick: Hall Effect Joystick, Infinite, Ultra-Linear, No Dead Zone, Recessed Design, Supports L3/R3 When Pressed Down Programmable Key: L4 and R4 Are Programmable Macro Keys Game Accessories Buttons: L1 And R1, L2 And R2 Are Linear Analog Trigger Buttons Game Function Buttons: ABXY, △○×□ Dual-Character Silk-Screen, Select Button, Start Button, Menu Button (Xbox) D-Pad: Integrated Directional Pad Handle Vibration: Dual-Linear Motor Sensor: 6-Axis Design: 3-Axis Accelerometer, 3-Axis Gyroscope Other Keys: "Gamepad/Mouse" Mode Switch Button |
| Battery | Battery Type: Lithium Polymer Battery Battery Capacity: 44.24Wh Battery Life: Heavy Use For 3 Hours, Moderate Use For 6-8 Hours, Light Use For 14 Hours, Depending On The Specific Usage Environment |
| Weight & Size | Product Weight: 0.52kg Package Weight: 1.32kg Product Size(L x W x H): 16.8 x 10.9 x 2.6cm Package Size(L x W x H): 21.5 x 16.9 x 7.3cm |
| Package Contents |
1 x GPD WIN Mini (2024) |
