Description:
Compared to the counterpart from other brands, what are the merits of F1? Overwhelming speed: 4000 mm/s ! Top one among all the glavo laser machines! We made it because we adopted the industrial grade galvo system, which guarantees precise and accurate engraving even at extreme speed. 5 secs, make a metal business card; 1 sec, make a paper card; 6 secs, make a leatherette patch. Super high engraving accuracy: 0.00199mm The world's first dual laser in a machine! No 2 laser heads. Safe and clean processing: Compatible with Desktop Smoke Purifier and RA2 Pro for xTool F1.
Specification:
Type: Details Laser type: 10W diode laser + 2W 1064nm infrared laser Product size: 179mm*235mm*334mm Product weight: 4.6kg Accuracy: Movement accuracy:0.00199mm Repeat positioning accuracy:0.000248mm Working area: 115*115mm rounded rectangle Expandable to 400*115mm with accessories Preview: Rect & Outline Preview speed: Rect:12000mm/s Outline:8000mm/s Up to working speed: 4000mm/s Applications: XCS / Lightburn Connection: WiFi & USB Support file: SVG / DXF / JPG / JPEG / PNG / BMP,etc. Support systems: Android / iOS / iPads / Windows /macOsS/
Input: 24V 5A
Features:
The Fastest and Finest of Its Kind Adopting TURE Industrial-grade galvanometer system, xTool F1 guarantees the extraordinary laser performance. Feel the True 4000mm/s Engraving Speed The extremely-high engraving speed is achieved by the advanced galvo technology. By precisely rotating and adjusting the galvanometer x-axis and y-axis mirrors in a high speed, the mirrors deflect the laser beam with various angles to the engraved objects in no time. See the 0.00199mm Engraving Accuracy Metal-made with sturdy structure and precise control of the moving laser beam, xTool F1 ensures the high engraving accuracy. All tiny details of the engraving can be shown clearly. Vector Image Font size down to 0.3mm Two Powerful Lasers in One Machine The world's first laser engraver that integrates a 2W 1064nm infrared laser with a 10W 455nm diode laser. Laser Engraving Dual lasers combine the advantages of the two, bringing the best engraving result and expanding the range of material that can be engraved. Laser Cutting The 10W blue laser gives xTool F1 enough power to directly cut materials after engraving. Intelligent in Design Different from time-consuming manual adjustment of traditional engravers, xTool F1 provides a more friendly and efficient way to set up the machine. Auto/Manual Focus Auto: Enter the material thickness in software, the laser head will automatically move to keep it in focus Manual: Turn the knob to adjust the height of the laser head to make sure the two red dots overlap. Live Engraving Preview Preview the design at exactly the position where you are to engrave with the harmless high-speed light running.
