Features

Football Mode for Brilliant Audiovisual Experience
Native 1080P Full HD
Up to 3200 Lumens

Specifications

Resolution
1080p (1920×1080)
Brightness (ANSI lumens)
3200lm
Contrast Ratio (FOFO)
10000:1
Speaker
10W x 1
All Specifications
Display
Projection System
DLP
Resolution
1080p (1920×1080)
Resolution Support
VGA(640 x 480) to WUXGA_RB (1920 x 1200) *RB = Reduced Blanking
Brightness (ANSI lumens)
3200lm
Contrast Ratio (FOFO)
10000:1
Display Color
1.07 billion colors
Native Aspect Ratio
16:9
Light Source
Lamp
Light Source Wattage
210W
Light Source Life
Normal 3500 hours
Economic 5000 hours
SmartEco 7000 hours‎

Optical
Throw Ratio
1.15 – 1.5 (100″@2.5m)
Zoom Ratio
1.3x
Lens
F=2.59~2.87, f=16.88~21.88
Keystone Adjustment
1D, Vertical +/- 40 degrees‎
Projection Offset
115%±5%‎
Clear Image Size (Diagonal)
60″~180″‎
Image Size
60”~ 300″‎
Horizontal Frequency
15K~102KHz
Vertical Scan Rate
23~120Hz
Picture Mode
Bright/ Football/ Football(Bright)/ Cinema/ Game/ User‎
Color Wheel Segment
RGBYCW
Color Wheel Speed
2x (60Hz), 3x (50Hz)

Audio
Speaker
10W x 1
Interface
PC (D-Sub)
1
Composite Video in (RCA)
1
Component Video In
1 (Share with D-Sub)
HDMI
2
HDMI-1 (1.4b/HDCP1.4)
HDMI-2 (1.4ba/MHL/HDCP1.4)
USB Type A
1
USB Type A-1 (2.0/Power Supply1.5A)
USB Type mini B
1 (Service)
Audio in (3.5mm Mini Jack)
1
Audio L/R in (RCA)
1
Audio out (3.5mm Mini Jack)
1
RS232 (DB-9pin)
1
IR Receiver
2 (Front & Rear)
Security Bar
1
Special Feature
CinemaMaster Audio +
Yes

Compatibility
HDTV Compatibility
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility
EDTV/ HDTV/ NTSC/ PAL/ SDTV‎/ SECAM
3D Compatibility‎
Frame Sequential: Up to 720p 60Hz
Frame Packing: Up to1080p 24Hz
Side by Side: Up to 1080i/p 24Hz
Top Bottom: Up to 1080p‎ 60Hz

Environment
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption
270 W
Standby Power Consumption
<0.5W
Acoustic Noise (Typ./Eco.)
34/29 dBA
Operating Temperature
0~40?
Dimension and Weight
Dimensions (W x H x D)(mm)
346.24 x 101.70 x 214.81 mm
Net Weight (Kg/ lbs)
2.65 kg (5.84 lbs)

Accessories (Standard)
Carton
Yes
Remote Control w/ Battery
Yes
Power Cord (by region)
1 (1.8M)
User Manual CD
1 (25L)
Quick Start Guide
1 (19L)
Warranty Card (by region)
Yes
VGA(D-sub 15pin) Cable
1 (1.8M)
Battery
AAA x2

Accessories (Optional)
Carry Bag
Yes (5J.J4N09.001)
Spare Lamp Kit
Yes
3D Glasses
Yes
Wireless FHD Kit
Yes, WDP02

OSD
OSD Language
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese(28 Languages)‎
