Specifications:

Brand: AlgolaserDelta

Laser information:
Laser Module Size:132mm x 63mm x 60mm
Laser Module Weight:750grams - 1.6 Pounds
Optical Power Output:19.5 to 22W, Average 20W, Acceptable Power Output Variation +5%
Laser Output Wavelenght: 445nm (+-5nm)
Focal Distance: 55 mm (From Module Radiator to Material)
Spot Size: At 3% power: X 0.06mm - Y 0.05mm, At 100% power: X 0.16mm - Y 0.14mm, Click HERE to understand how Spot Size is tested
Spot Shape: Square
Operating Frequency: <30KHz
Operating Temperature: -10ºC - +40º | 14ºF - 104ºF, Multiple Optical Lens Assembly
Diodes Input Voltage: 8.60 Volts
Diodes Inpute Current: 3.8 Amps
Harness Specification: Data Line 4x 26AWG - 0.14 (mm2 cross-sectional area), Laser Line 4x 22AWG - 0.34 (mm2 cross-sectional area)
Connectors Type: Data Line - PHB 2.0 4Pin, Laser Line -
Life Expectancy: >10,000 Hours
Optical Lense Material: Professional focusing optical glass (quartz glass), Multiple Optical Lens Assembly

Machine information:
Optical Power: 22W
Machine Power: 144W
Power Supply: 24V/6A
Maximum Engraving Speed: 30,000 mm/min
Maximum Motion Speed: 50,000 mm/min
Spot Size: 0.16*0.14mm 100% Power / 0.06*0.05mm 3% Power
Product Size: X650*Y730*Z175mm
Product Weight: 8.5KG
Laser Head Life Expectancy: >8000 hours
Certification: FCC/CE/RoHS/FDA
Safety Features: Active Power-Out detection and protection, Laser Over-Exposure Time Limit, USB disconnect shutdown, Emergency stop button, Gyroscope detection,Motherboard over-temperature protection

Software and Connection:
System Supported: Android, iOS, Windows, for Mac OS, Web-based
Control Software: AlgoLaser App / LightBurn/LaserGRBL
Compatible Accessories: 22W laser module, Motorized Z-axis, Engraving Platform, Fireproof Box, Rotary Chuck, Rotary Roller
File Format Supported: JPG, SVG, PNG, BMP, G-code, CAD, AI, CDR, DWG, etc.

Features:
1. Expansive 440*415mm working area enables large-scale lattice creations.
2. Ultra-fast 500mm/sec engraving speed enhances productivity.
3. Inbuilt smart air pump for efficient operation.
4. Rapid image engraving - streamlined uploading and engraving via the control screen.
5. Advanced semiautomatic focus to ensure precision.
6. Incorporated smart safety features minimizing the potential for operational malfunctions.
7. Enhanced 2nd generation COS optical technology propels laser efficiency and output.

Package Include:
1 x Front Assembly

1 x Left Axis Y Assembly
1 x Rear Panel Assembly
1 x X-Axis Assembly
1 x Motor Extension Shaft
1 x LB- 20A Laser Module
1 x Laser Shi-eld
1 x Replacement Nut
1 x Lens Tool

1 x Air Assist Nozzle
1 x Replacement Lens
1 x 0 Replacement O-Ring
1 x Lens Finger Guard
1 x AlgoLaser Air pump(AAP 1.0)
1 x Air Pipe

1 x Plywood
1 x Acrylic

3 x MetalCard
17 x M4X12 Screw
1 x M2.5 Allen Key
2 x M4X16 Screw
1 x M3.0 Allen Key

1 x Machine Key Set
1 x USB Cable
2 x Coupling
1 x Power Cable
1 x Laser Goggle
1 x Power Adapter
1 x Brush
